CE certified · Oval screen printing machine engineered for footwear materials
H18 is purpose-built for footwear printing. Servo control combined with custom pallets keeps registration stable on mesh, leather and other textured or curved substrates, covering athletic, casual and leather uppers with reliable multicolor and gradient output.
| Model | H18-6 | H18-10 | H18-14 | H18-16 | H18-20 | H18-24 | H18-28 | H18-32 | H18-36 |
|---|---|---|---|---|---|---|---|---|---|
| QTY Printing Heads | 6 | 10 | 14 | 16 | 20 | 24 | 28 | 32 | 36 |
| Printing Area (cm×cm) | 50 × 60 | ||||||||
| Max. Screen Size L×W (cm) | 67 × 94 | ||||||||
| Power Voltage | 380V; 50Hz | ||||||||
| Printing Head Power (kW) | 0.375×6 | 0.375×10 | 0.375×14 | 0.375×16 | 0.375×20 | 0.375×24 | 0.375×28 | 0.375×32 | 0.375×36 |
| Main Motor (kW) | 3.7×1 | 3.7×2 | 3.7×2 | 3.7×2 | 3.7×2 | 3.7×2 | 3.7×2 | 3.7×2 | 3.7×2 |
| QTY Pallets | 32 | 48 | 64 | 72 | 88 | 104 | 120 | 136 | 152 |
| Production (H18-16 colors) | 600 pcs/h | ||||||||
| Air Pressure (MPa) | 0.6 – 0.8 | ||||||||
| Gas (L/min) | 350 – 2500 | ||||||||
| Weight (kg) | 2500 | 3500 | 4500 | 5000 | 6000 | 7000 | 8000 | 9000 | 10000 |
