CTS-1015M Laser Exposure Machine

Industrial 405 nm direct laser imaging (CTS) exposure machine with DMD XGA imaging unit, fiber-optic laser delivery, dynamic real-time autofocus and 12700 dpi resolution — built for premium screen making in mid-volume shops.

20W laser power, 405 nm fiber delivery
DMD XGA imaging unit, 12700 dpi resolution
Dynamic real-time autofocus + auto alignment
1100 × 1250 mm max exposure area

• Technical Specifications

Model
CTS-1015M

Min frame size
400 × 400 mm

Frame thickness
20 – 40 mm

Laser power
20 W

Laser delivery
Fiber optic

Image resolution
12700 dpi

Coating uniformity
± 5%

Data interface
Ethernet

Exposure time
3 – 4 min (1000 × 1000 mm)

Weight
2600 kg

Operating environment
18 – 25 °C, 40 – 60% humidity

Power
Single-phase 220V / 50 – 60 Hz / 4 kW (well grounded)

Max frame size
1300 × 1200 mm

Max exposure area
1100 × 1250 mm

Imaging unit
DMD XGA

Laser wavelength
405 nm

Focus
Dynamic real-time autofocus

Film thickness
6 – 50 μm

Line width
50 μm

Input file format
Gerber 274X

Dimensions
2950 × 1900 × 1650 mm

Support points
4 points (10 kN / ø120 mm each)

Air pressure
5 – 6 bar
